How to use the Object API / ObjectServiceClient

Introduction

Objects are the primary resource to actually hold the data you upload. Before you can initialize any Objects you have to create a Collection to ensure consistent authorization for all

If you don't know how to create a Collection you should read the previous chapter about the Collection API basics.

Initialize Object

The first step is to initialize an Object. This creates an Object in the AOS with a status of Initializing and marks it as Staging. As long as an Object is in the staging area data can be uploaded to it.

Hash validation

If you provide a hash with the initializing of an Object it will be automatically validated by the DataProxy after the data upload has been finished. This ensures that the upload was successful and complete.

Info

This request needs at least APPEND permissions on the Object's Collection or the Project under which the Collection is registered.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
# Native JSON request to initialize a staging object
curl -d '
  {
    "object": {
      "filename": "aruna.png",
      "contentLen": "123456",
      "dataclass": "DATA_CLASS_PRIVATE",
      "labels": [
        {
          "key": "LabelKey",
          "value": "LabelValue"
        }
      ],
      "hooks": [],
      "subPath": ""
    },
    "preferredEndpointId": "",
    "multipart": false,
    "isSpecification": false,
    "hash": {
        "alg": "HASHALGORITHM_SHA256",
        "hash": "5839942d4f1e706fee33d0837617163f9368274a72b2b7e89d3b0877f390fc33"
    }
  }' \
  -H 'Authorization: Bearer <API_TOKEN>' \
  -H 'Content-Type: application/json' \
  -X POST https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
// Create tonic/ArunaAPI request to initialize an staging object
let init_request = InitializeNewObjectRequest {
    object: Some(StageObject {
        filename: "aruna.png".to_string(),
        content_len: 123456,
        source: None,
        dataclass: DataClass::Private as i32,
        labels: vec![KeyValue {
            key: "LabelKey".to_string(),
            value: "LabelValue".to_string(),
        }],
        hooks: vec![KeyValue {
            key: "HookKey".to_string(),
            value: "HookValue".to_string(),
        }],
        sub_path: "".to_string(),
    }),
    collection_id: "<collection-id>".to_string(),
    preferred_endpoint_id: "".to_string(),
    multipart: false,
    is_specification: false,
    hash: Some(Hash {
        alg: Hashalgorithm::Sha256 as i32,
        hash: "5839942d4f1e706fee33d0837617163f9368274a72b2b7e89d3b0877f390fc33".to_string(),
    },
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.initialize_new_object(init_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
# Create tonic/ArunaAPI request to initialize an staging object
request = InitializeNewObjectRequest(
    object=StageObject(
        filename="aruna.png",
        content_len=123456,
        source=None,  # Parameter can also be omitted if None
        dataclass=DataClass.Value("DATACLASS_PRIVATE"),
        labels=[KeyValue(
            key="LabelKey",
            value="LabelValue"
        )],
        hooks=[KeyValue(
            key="HookKey",
            value="HookValue"
        )],
        subPath="",  # Parameter can also be omitted if empty
    ),
    collection_id="<collection-id>",
    preferred_endpoint_id="",  # Parameter can also be omitted if empty
    multipart=False,
    is_specification=False,
    hash=Hash(
        alg=Hashalgorithm.Value("HASHALGORITHM_SHA256"),
        hash="5839942d4f1e706fee33d0837617163f9368274a72b2b7e89d3b0877f390fc33"
    )
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.InitializeNewObject(request=request)

# Do something with the response
print(f'{response}')

Upload data to an Staging Object

After initializing an Object you can request an upload url with the object id you received from the initialization. Data then can be uploaded through the received url to the AOS data proxy.

If the data associated with the Object is greater than 5 Gigabytes you have to request a multipart upload and chunk your data in parts which are at most 5 Gigabytes in size. You also have to request an upload url for each part individually.

S3 Presigned download URL

You can also generate presigned URLs on your own for the specific AOS DataPoxy you want to upload the Object data to.

Info

Requesting an upload URL needs at least APPEND permissions on the Object's Collection or the Project under which the Collection is registered.

Single part upload

Info

Single part upload automatically starts the finishing process of the respective Object once the upload has been finished to make it available.

1
2
3
4
5
6
7
# Native JSON request to request an upload url for single part upload
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/staging/{upload-id}/upload

# Native JSON request to upload single part data through the generated data proxy upload url
curl -X PUT -T <path-to-local-file> <upload-url>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
// Create tonic/ArunaAPI request to request an upload url for single part upload
let get_request = GetUploadUrlRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    upload_id: "<upload-id>".to_string(),
    multipart: false,
    part_number: 1,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_upload_url(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);
let upload_url = response.url.unwrap().url;

// Upload local file to the generated upload URL
let path = Path::new("/path/to/local/file");
let file = tokio::fs::File::open(path).await.unwrap();

let client = reqwest::Client::new();
let stream = FramedRead::new(file, BytesCodec::new());
let body   = Body::wrap_stream(stream);

// Send the request to the upload url
let response = client.put(upload_url)
                     .body(body)
                     .send()
                     .await
                     .unwrap();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
# Create tonic/ArunaAPI request to request an upload url for single part upload
request = GetUploadURLRequest(
    object_id="<object-id>",
    upload_id="<upload-id>",
    collection_id="<collection-id>",
    multipart=False,
    part_number=1
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetUploadURL(request=request)

# Do something with the response
print(f'{response}')
upload_url = response.url.url

# Upload local file to the generated upload URL
file_path = "/tmp/aruna.png"
headers = {'Content-type': 'application/octet-stream'}
upload_response = requests.put(upload_url, data=open(file_path, 'rb'), headers=headers)

# Do something with the response
print(f'{upload_response}')

Multipart upload

Note

For each uploaded part of the multipart upload you will receive a so called ETag in the response header which has to be saved with the correlating part number for the Object finishing.

Numbers of upload parts start with 1, not 0.

Multipart uploads have to be finished manually as the DataProxy cannot know or guess how many parts will be uploaded in total.

Tip

Upload of parts from multipart upload can be uploaded parallel.

Warning

If the data is stored in an S3 endpoint individual parts of multipart upload have to be at least 5MiB in size (5242880 bytes) or the Object finishing will fail.

1
2
3
4
5
6
7
# Native JSON request to request an upload url for specific part of multipart upload
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/staging/{upload-id}/upload?multipart=true&partNumber=<part-number>

# Upload multipart data with native JSON requests through the generated data proxy upload urls
curl -X PUT -T <path-to-local-file> <upload-url>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
// Create tonic/ArunaAPI to request an upload url for specific part of multipart upload
let get_request = GetUploadUrlRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    upload_id: "<upload-id>".to_string(),
    multipart: true,
    part_number: <part-number> as i32,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_upload_url(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
# Create tonic/ArunaAPI request to request an upload url for specific part of multipart upload
request = GetUploadURLRequest(
    object_id="<object-id>",
    upload_id="<upload-id>",
    collection_id="<collection-id>",
    multipart=True,
    part_number=<part-number>
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetUploadURL(request=request)

# Do something with the response
print(f'{response}')
Multipart upload example
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
COLLECTION_ID=<collection-id>
OBJECT_ID=<staging-object-id>
UPLOAD_ID=<objects-upload-id>

# Loop over all file parts, request an upload url, upload the data and display ETag with its part number
for i in "Dummy_Archive.tar.gz.aa",1 "Dummy_Archive.tar.gz.ab",2 "Dummy_Archive.tar.gz.ac",3 "Dummy_Archive.tar.gz.ad",4;
  do IFS=","; # Split input at comma
  set -- $i;  # Convert the "tuple" into the param args $1 $2 ...
    PART_FILE=$1
    PART_NUM=$2

    UPLOAD_URL=$(curl -s -H "$API_HEADER" \
                         -H 'Content-Type: application/json' \
                         -X GET "https://<URL-to-AOS-instance-API-gateway>/v1/collection/${COLLECTION_ID}/object/${OBJECT_ID}/staging/${UPLOAD_ID}/upload?multipart=true&partNumber=${PART_NUM}" | jq -r '.url.url')
    ETAG=$(curl -X PUT -T ${PART_FILE} -i "${UPLOAD_URL}" | grep etag)

    echo -e "\nPart: ${PART_NUM}, ETag: ${ETAG}\n"
done

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
let mut file = tokio::fs::File::open("/path/to/local/file").await.unwrap();     // File handle
let mut remaining_bytes: usize = file.metadata().await.unwrap().len() as usize; // File size in bytes
let mut upload_part_counter: i64 = 0;
let mut completed_parts: Vec<CompletedParts> = Vec::new();

const UPLOAD_BUFFER_SIZE: usize = 1024 * 1024 * 50; // 50MiB chunks
let mut buffer_size = UPLOAD_BUFFER_SIZE;           // Variable buffer size for loop

loop {
    // Increment part number
    upload_part_counter += 1;

    // Set buffer size
    if remaining_bytes < UPLOAD_BUFFER_SIZE {
        buffer_size = remaining_bytes;
    }

    // Fill buffer with bytes from file
    let mut data_buf = vec![0u8; buffer_size];
    let successful_read = file.read_exact(&mut data_buf).await;

    match successful_read {
        Ok(bytes) => bytes,
        Err(_) => file.read_to_end(&mut data_buf).await.unwrap(),
    };

    // Create tonic/ArunaAPI request to request an upload url for multipart upload part
    let upload_url = object_client
        .get_upload_url(GetUploadUrlRequest {
            object_id: object_id.to_string(),
            upload_id: upload_id.to_string(),
            collection_id: collection_id.to_string(),
            multipart: true,
            part_number: upload_part_counter as i32,
        })
        .await
        .unwrap()
        .into_inner()
        .url.unwrap().url;

    // Upload buffer content to upload url and parse ETag from response header
    let client   = reqwest::Client::new();
    let response = client.put(upload_url).body(data_buf).send().await.unwrap();
    let etag_raw = response.headers().get("ETag").unwrap().as_bytes();
    let etag     = std::str::from_utf8(etag_raw).unwrap().to_string();

    // Collect ETag with corresponding part number
    completed_parts.push(CompletedParts {
        etag: etag,
        part: upload_part_counter,
    });

    // Update the amount of remaining bytes for the next loop
    remaining_bytes -= buffer_size;
    if remaining_bytes == 0 {
        break;
    }
}

// Retain the completed parts for usage in the FinishObjectRequest
println!("{:#?}", completed_parts);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
CHUNK_SIZE = 1024 * 1024 * 50;  # 50MiB chunks

file_path = "/path/to/local/file"
headers = {'Content-type': 'application/octet-stream'}  # Arbitrary binary data upload
completed_parts = []

# Open file and return a stream
with open(file_path, 'rb') as file_in:
    for i, data_chunk in enumerate(read_file_chunks(file_in, CHUNK_SIZE)):  # (1)
        # Create tonic/ArunaAPI request to request an upload url for multipart upload part
        get_request = GetUploadURLRequest(
            object_id="<object-id>",
            upload_id="<upload-id>",
            collection_id="<collection-id>",
            multipart=True,
            part_number=i+1
        )

        # Send the request to the AOS instance gRPC gateway
        get_response = client.object_client.GetUploadURL(request=get_request)

        # Extraxt download url from response
        upload_url = get_response.url.url

        # Upload file content chunk to upload url
        upload_response = requests.put(upload_url, data=data_chunk, headers=headers)

        # Parse ETag from response header
        etag = str(upload_response.headers["etag"].replace("\"", ""))

        # Collect ETag with corresponding part number
        completed_parts.append(
            CompletedParts(
                etag=etag,
                part=i+1
            )
        )

# Retain the completed parts for usage in the FinishObjectRequest
print(f'{completed_parts}')
  1. This function returns a generator with byte chunks of the specified file:
     1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
        def read_file_chunks(file_object, chunk_size=5242880):
    """
    Generator to read set chunk sizes of a file object.
    Args:
        file_object: Open file handle
        chunk_size: Size of chunk to read (Default: 5MiB)

    Returns: Generator with file content bytes in chunk size
    """
    while True:
        data = file_object.read(chunk_size)
        if not data:
            break
        yield data

Finish Object

Finishing the Object transfers it from the staging area into production i.e. makes it available. From this moment the Object is generally available for other functions other than Get Object. On success the response will contain all the information on the finished Object.

Info

Object finishing is only needed in the following cases:

  • Object created/updated without upload
  • Object created/updated with multipart upload

Single part upload automatically starts the finishing process of the respective Object once the data upload has been finished.

Info

This request needs at least APPEND permissions on the Object's Collection or the Project under which the Collection is registered.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
# Native JSON request to finish a staging object without upload
curl -d '
  {
    "hash": {},
    "noUpload": true,
    "completedParts": [],
    "autoUpdate": true
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X PATCH https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/staging/{upload-id}/finish

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
# Native JSON request to finish a multipart upload staging object
curl -d '
  {
    "hash": {
      "alg": "HASHALGORITHM_SHA256",
      "hash": "5839942d4f1e706fee33d0837617163f9368274a72b2b7e89d3b0877f390fc33"
    },
    "noUpload": false,
    "completedParts": [
      {
        "etag": "<etag-of-part-number-upload>",
        "part": "<part-number>"
      },
      {
        "etag": "<etag-of-part-number-upload>",
        "part": "<part-number>"
      }
    ],
    "autoUpdate": true
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X PATCH https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/staging/{upload-id}/finish

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
// Create tonic/ArunaAPI request to finish a staging object without upload
let finish_request = FinishObjectStagingRequest {
    object_id: "<object-id>".to_string(),
    upload_id: "<upload-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    hash: None,
    no_upload: true,
    completed_parts: vec![],
    auto_update: true,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.finish_object_staging(finish_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
// Create tonic/ArunaAPI request to finish a multipart upload staging object
let finish_request = FinishObjectStagingRequest {
    object_id: "<object-id>".to_string(),
    upload_id: "<upload-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    hash: Some(Hash {
        alg: Hashalgorithm::Sha256 as i32,
        hash: "5839942d4f1e706fee33d0837617163f9368274a72b2b7e89d3b0877f390fc33".to_string()
    }),
    no_upload: false,
    completed_parts: vec![
        CompletedParts {
            etag: "bfa7d257edcc9b962b7ab1a0a75b9808".to_string(),
            part: 1,
        },
        CompletedParts {
            etag: "af62c64eb6bcc9890d0aadf5720bf1ff".to_string(),
            part: 2,
        },
    ],
    auto_update: true,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.finish_object_staging(finish_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
# Create tonic/ArunaAPI request to finish a staging object without upload
request = FinishObjectStagingRequest(
    object_id="<object-id>",
    upload_id="<upload-id>",
    collection_id="<collection-id>",
    hash=None,  # Parameter can also be omitted if None
    no_upload=True,
    completed_parts=[],  # Parameter can also be omitted if empty
    auto_update=True
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.FinishObjectStaging(request=request)

# Do something with the response
print(f'{response}')

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
# Create tonic/ArunaAPI request to finish a multipart upload staging object
finish_request = FinishObjectStagingRequest(
    object_id="<object-id>",
    upload_id="<upload-id>",
    collection_id="<collection-id>",
    hash=Hash(
        alg=Hashalgorithm.Value("HASHALGORITHM_SHA256"),
        hash="<sha256-file-hashsum>"  # E.g. 5839942d4f1e706fee33d0837617163f9368274a72b2b7e89d3b0877f390fc33
    ),
    no_upload=False,
    completed_parts=[
        CompletedParts(
            etag="<upload-etag>",  # E.g. bfa7d257edcc9b962b7ab1a0a75b9808
            part=1
         ),
        CompletedParts(
            etag="<upload-etag>",  # E.g. af62c64eb6bcc9890d0aadf5720bf1ff
            part=2
        )
    ],
    auto_update=True
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.FinishObjectStaging(request=request)

# Do something with the response
print(f'{response}')

Get Object

Information on finished or staging Objects can be fetched with their id and the id of their Collection.

The with_url (or withUrl) parameter controls if the response includes a download URL for the specific Object.

Info

This request needs at least READ permissions on the Object's Collection or the Project under which the Collection is registered.

1
2
3
4
# Native JSON request to fetch information of an object by its unique id
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}

1
2
3
4
# Native JSON request to fetch information of an object by its unique id including a download url
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}?withUrl=true

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
// Create tonic/ArunaAPI request to fetch information of an object
let get_request = GetObjectByIdRequest {
    collection_id: "<collection-id>".to_string(),
    object_id: "<object-id>".to_string(),
    with_url: false
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_object(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# Create tonic/ArunaAPI request to to fetch information of an object
request = GetObjectByIDRequest(
    object_id="<object-id>",
    collection_id="<collection-id>",
    with_url=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetObjectByID(request=request)

# Do something with the response
print(f'{response}')

Get Objects

You can also fetch information on multiple Objects of a Collection with a single request. The Objects returned will not include staging Objects.

By default, this request also returns only the first 20 Objects. You can either increase the page size to receive more Objects per request and/or request the next Objects by pagination. Additionally, you can include id or label filters to narrow the returned Objects.

The with_url (or withUrl) parameter controls if the response includes a download URL for each of the returned Objects.

Info

This request needs at least READ permissions on the Object's Collection or the Project under which the Collection is registered.

1
2
3
4
# Native JSON request to fetch information of the first 20 unfiltered objects in a collection with download URLs
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/objects?withUrl=true

1
2
3
4
# Native JSON request to fetch information of the first 250 unfiltered objects in a collection
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/objects?pageRequest.pageSize=250

1
2
3
4
# Native JSON request to fetch information of the objects 21-40 (i.e. the next page) in a collection
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/objects?pageRequest.lastUuid=<id-of-last-received-object>

1
2
3
4
# Native JSON request to fetch information of all objects in a collection matching one of the provided ids
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/objects?labelIdFilter.ids=<object-id-001>&labelIdFilter.ids=<object-id-002>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
// Create tonic/ArunaAPI to fetch information of the first 20 unfiltered objects in a collection with download URLs
let get_request = GetObjectsRequest {
    collection_id: "<collection-id>".to_string(),
    page_request: None,
    label_id_filter: None,
    with_url: true,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_objects(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
// Create tonic/ArunaAPI to fetch information of the first 250 unfiltered objects in a collection
let get_request = GetObjectsRequest {
    collection_id: "<collection-id>".to_string(),
    page_request: Some(PageRequest {
        last_uuid: "".to_string(),
        page_size: 250,
    }),
    label_id_filter: None,
    with_url: false,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_objects(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
// Create tonic/ArunaAPI to fetch information of the objects 21-40 (i.e. the next page) in a collection
let get_request = GetObjectsRequest {
    collection_id: "<collection-id>".to_string(),
    page_request: Some(PageRequest {
        last_uuid: "<id-of-last-received-object>".to_string(),
        page_size: 0,
    }),
    label_id_filter: None,
    with_url: false,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_objects(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
// Create tonic/ArunaAPI to fetch information of all objects in a collection matching one of the provided ids
let get_request = GetObjectsRequest {
    collection_id: "<collection-id>".to_string(),
    page_request: None,
    label_id_filter: Some(LabelOrIdQuery {
        labels: None,
        ids: vec!["<object-id-001>".to_string(), "<object-id-001>".to_string()],
    }),
    with_url: false,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_objects(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
// Create tonic/ArunaAPI to fetch multiple object of a collection filtered by label key(s)
let get_request = GetObjectsRequest {
    collection_id: "<collection-id>".to_string(),
    page_request: None,
    label_id_filter: Some(LabelOrIdQuery {
        labels: Some(LabelFilter {
            labels: vec![KeyValue {
                key: "LabelKey".to_string(),
                value: "".to_string(),
            }],
            and_or_or: false,
            keys_only: true,
        }),
        ids: vec![],
    }),
    with_url: false,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_objects(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
# Create tonic/ArunaAPI request to fetch information of the first 20 unfiltered objects in a collection with download URLs
request = GetObjectsRequest(
    collection_id="<collection-id>",
    page_request=None,
    label_id_filter=None,
    with_url=True
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetObjects(request=request)

# Do something with the response
print(f'{response}')

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
# Create tonic/ArunaAPI request to fetch information of the first 250 unfiltered objects in a collection
request = GetObjectsRequest(
    collection_id="<collection-id>",
    page_request=PageRequest(
        last_uuid="",  # Parameter can also be omitted if empty
        page_size=250
    ),
    label_id_filter=None,
    with_url=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetObjects(request=request)

# Do something with the response
print(f'{response}')

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
# Create tonic/ArunaAPI request to fetch information of the objects 21-40 (i.e. the next page) in a collection
request = GetObjectsRequest(
    collection_id="<collection-id>",
    page_request=PageRequest(
        last_uuid="<last-received-object-id>",
        page_size=0  # Parameter can also be omitted if <= 0
    ),
    label_id_filter=None,  # Parameter can also be omitted if None
    with_url=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetObjects(request=request)

# Do something with the response
print(f'{response}')

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
# Create tonic/ArunaAPI request to fetch information of all objects in a collection matching one of the provided ids
request = GetObjectsRequest(
    collection_id="<collection-id>",
    page_request=None,  # Parameter can also be omitted if None
    label_id_filter=LabelOrIDQuery(
        labels=None,  # Parameter can also be omitted if None
        ids=["<object-id-001>", "<object-id-001>"]
    ),
    with_url=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetObjects(request=request)

# Do something with the response
print(f'{response}')

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
# Create tonic/ArunaAPI request to fetch multiple objects of a collection filtered by label key(s)
request = GetObjectsRequest(
    collection_id="<collection-id>",
    page_request=None,  # Parameter can also be omitted if None
    label_id_filter=LabelOrIDQuery(
        labels=LabelFilter(
            labels=[KeyValue(
                key="isDummyObject",
                value=""  # Parameter can also be omitted if empty or keys_only=True
            )],
            and_or_or=False,
            keys_only=True
        )
    ),
    with_url=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetObjects(request=request)

# Do something with the response
print(f'{response}')

Download Object data

To download the data associated with an Object you have to request a download url. This can be done with an individual request or directly while getting information on an Object.

S3 Presigned download URL

You can also generate presigned URLs on your own for the specific AOS DataPoxy you want to download the Object data from.

Info

This request needs at least READ permissions on the Object's Collection or the Project under which the Collection is registered.

1
2
3
4
5
6
7
# Native JSON request to fetch an Objects download url
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/download

# Download the data with the provided remote file name
curl -J -O -X GET <received-download-url>

1
2
3
4
5
6
7
# Native JSON request to fetch information of an Object including its download id
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}?withUrl=true

# Download the data
curl -J -O -X GET <received-download-url>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
// Send GET request to download url
let response = reqwest::get(download_url).await.unwrap();

// Only proceed if response status is ok
if response.status() != StatusCode::OK {
    panic!("Get request for file download failed.");
}

// Set default filename to "object.<object-id>"
let mut file_name = format!(
    "object.{}",
    response.url().path_segments().unwrap().last().unwrap()
);

// Try to extract filename from download url query parameter
for elem in response.url().query_pairs() {
    if elem.0 == "filename" {
        file_name = elem.1.to_string();
    }
}

// Create local file
let target_path = Path::new("/tmp").join();
let mut target_file = File::create(target_path).unwrap();

// Write response content to file
let mut content = Cursor::new(response.bytes().await.unwrap());
copy(&mut content, &mut target_file).unwrap();

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
# Create tonic/ArunaAPI request to fetch an Objects download url
download_url_request = GetDownloadURLRequest(
    collection_id="<collection-id>",
    object_id="<object-id>"
)

# Send the request to the AOS instance gRPC gateway
download_url_response = client.object_client.GetDownloadURL(request=download_url_request)

# Extract download url from response
download_url = download_url_response.url.url

# Try to extract filename from download url query parameter
parsed_url = urlparse(download_url)
local_filename = parse_qs(parsed_url.query)['filename'][0]

if local_filename is None:
    local_filepath = os.path.join("/tmp", f'object.{object_id}')
else:
    local_filepath = os.path.join("/tmp", local_filename)

# Send GET request to download url
with requests.get(download_url, stream=True) as r:
    r.raise_for_status()

    // Write response content in chunks to local file
    with open(local_filepath, 'wb') as f:
        for chunk in r.iter_content(chunk_size=8192):  # Chunk size can be adapted
            f.write(chunk)

Update Object

Objects can still be updated after finishing.

When an update is started, a staging Object with the status Initializing is created in the specific collection. Only one staging object per object can exist at a time, so parallel updates of an object are prohibited. This limitation is due to the S3 compatibility of the AOS, but also helps to maintain the consistency of the revision hierarchy.

Info

This request needs at least MODIFY permissions on the Object's Collection or the Project under which the Collection is registered.

Update which does not create a new revision

Just adding one or multiple labels to an Object does not create a new revision with this specific request.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
# Native JSON request to add a label to an object
curl -d '
  {
    "labelsToAdd": [
      {
        "key": "AnotherKey",
        "value": "AnotherValue"
     }
   ]
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X PATCH https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/add_labels

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
// Create tonic/ArunaAPI request to add a label to an object
let add_request = AddLabelsToObjectRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    labels_to_add: vec![KeyValue {
        key: "AnotherKey".to_string(),
        value: "AnotherValue".to_string(),
    }],
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.add_label_to_object(add_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
# Create tonic/ArunaAPI request to add a label to an object
request = AddLabelsToObjectRequest(
    object_id="<object-id>",
    collection_id="<collection-id>",
    labels_to_add=[KeyValue(
        key="AnotherKey",
        value="AnotherValue"
    )]
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.AddLabelsToObject(request=request)

# Do something with the response
print(f'{response}')

Update which creates a new revision

Every other update creates a new revision of an Object and basically an updated clone of the Object. A regular update of an Object returns the updated Object which is still in the staging area. Comparable to the Object initialization process, the updated Object must be finished before it is generally available.

Warning

An object update overwrites all the fields in the request, even if they're empty. If you want to retain a field you have to explicitly set the old value.

Update without data re-upload

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
# Native JSON request to update an objects dataclass
curl -d '
  {
    "object": {
      "filename": "aruna.png",
      "contentLen": "123456",
      "dataclass": "DATA_CLASS_PUBLIC",
        "labels": [
          {
            "key": "LabelKey",
            "value": "LabelValue"
          }
        ],
        "hooks": [],
        "subPath": ""
      },
    "reupload": false,
    "preferredEndpointId": "",
    "multiPart": false,
    "isSpecification": false,
    "force": false,
    "hash": {}
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/update

# Native JSON request to finish the updated object
curl -d '
  {
    "hash": {},
    "noUpload": true,
    "completedParts": [],
    "autoUpdate": true
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X PATCH https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/staging/{upload-id}/finish

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
// Create tonic/ArunaAPI request to update an objects dataclass
let update_request = UpdateObjectRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    object: Some(StageObject {
        filename: "aruna.png".to_string(),
        content_len: 123456,
        source: None,
        dataclass: DataClass::Public as i32,
        labels: vec![KeyValue {
            key: "LabelKey".to_string(),
            value: "LabelValue".to_string(),
        }],
        hooks: vec![KeyValue {
            key: "HookKey".to_string(),
            value: "HookValue".to_string(),
        }],
        sub_path: "".to_string(),
    }),
    reupload: false,
    preferred_endpoint_id: "".to_string(),
    multi_part: false,
    is_specification: false,
    force: false,
    hash: None, // Not needed in case of no data upload
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.update_object(update_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);
let UpdateObjectResponse {object_id, staging_id, collection_id} = response;

// Create tonic/ArunaAPI request to finish the updated object
let finish_request = FinishObjectStagingRequest {
    object_id: object_id,
    upload_id_ staging_id,
    collection_id: collection_id,
    hash: None,
    no_upload: true,
    completed_parts: vec![],
    auto_update: true,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.finish_object_staging(finish_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
# Create tonic/ArunaAPI request to update an objects description
update_request = UpdateObjectRequest(
    object_id="<object-id>",
    collection_id="<collection-id>",
    object=StageObject(
        filename="aruna.png",
        content_len=123456,
        source=None,  # Parameter can also be omitted if None
        dataclass=DataClass.Value("DATACLASS_PUBLIC"),
        labels=[KeyValue(
            key="LabelKey",
            value="LabelValue"
        )],
        hooks=[KeyValue(
            key="HookKey",
            value="HookValue"
        )],
        subPath="",  # Parameter can also be omitted if empty
    ),
    reupload=False,
    preferred_endpoint_id="",  # Parameter can also be omitted if empty
    multi_part=False,  # Parameter can also be omitted if `reupload=False`
    is_specification=False,
    force=False,
    hash=None  # Not needed in case of no data upload
)

# Send the request to the AOS instance gRPC gateway
update_response = client.object_client.UpdateObject(request=update_request)

# Do something with the response
print(f'{update_response}')

# Create tonic/ArunaAPI request to finish a single part upload staging object
finish_request = FinishObjectStagingRequest(
    object_id=update_response.object_id,
    upload_id=update_response.upload_id,
    collection_id=update_response.collection_id,
    hash=None,
    no_upload=True,
    completed_parts=[],
    auto_update=True
)

# Send the request to the AOS instance gRPC gateway
finish_response = client.object_client.FinishObjectStaging(request=finish_request)

# Do something with the response
print(f'{finish_response}')

Update with data re-upload

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
# Native JSON request to re-upload the modified data
curl -d '
  {
    "object": {
      "filename": "aruna.png",
      "contentLen": "1234567",
      "dataclass": "DATA_CLASS_PRIVATE",
        "labels": [
          {
            "key": "LabelKey",
            "value": "LabelValue"
          }
        ],
        "hooks": [],
        "subPath": ""
      },
    "reupload": true,
    "preferredEndpointId": "",
    "multiPart": false,
    "isSpecification": false,
    "force": false,
    "hash": {}
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/update

# Native JSON request to request an upload url for single part upload
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/{collection-id}/object/{object-id}/staging/{upload-id}/upload

# Native JSON request to upload single part data through the generated data proxy upload url
curl -X PUT -T <path-to-local-file> <upload-url>

# Request to finish the updated object only needed in case of no upload or multipart upload

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
// Create tonic/ArunaAPI request to re-upload the modified data
let update_request = UpdateObjectRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    object: Some(StageObject {
        filename: "aruna.png".to_string(),
        content_len: 1234567,
        source: None,
        dataclass: DataClass::Private as i32,
        labels: vec![KeyValue {
            key: "LabelKey".to_string(),
            value: "LabelValue".to_string(),
        }],
        hooks: vec![KeyValue {
            key: "HookKey".to_string(),
            value: "HookValue".to_string(),
        }],
        sub_path: "".to_string(),
    }),
    reupload: true,
    preferred_endpoint_id: "".to_string(),
    multi_part: false,
    is_specification: false,
    force: false,
    hash: None, // Will be provided at object finish in this example
};

// Send the request to the AOS instance gRPC gateway
let update_response = object_client.update_object(update_request)
                                   .await
                                   .unwrap()
                                   .into_inner();

// Do something with the response
println!("{:#?}", update_response);
let UpdateObjectResponse {
    object_id,
    staging_id,
    collection_id
} = update_response;

// Create tonic/ArunaAPI request to request an upload url for single part upload
let get_request = GetUploadUrlRequest {
    object_id: object_id.clone(),
    collection_id: collection_id.clone(),
    upload_id: staging_id.clone(),
    multipart: false,
    part_number: 1,
};

// Send the request to the AOS instance gRPC gateway
let get_response = object_client.get_upload_url(get_request)
                                .await
                                .unwrap()
                                .into_inner();

// Do something with the response
println!("{:#?}", get_response);
let upload_url = get_response.url.unwrap().url;

// Upload local file to the generated upload URL
let path = Path::new("/path/to/local/file");
let file = tokio::fs::File::open(path).await.unwrap();

let client = reqwest::Client::new();
let stream = FramedRead::new(file, BytesCodec::new());
let body   = Body::wrap_stream(stream);

// Send the request to the upload url
let upload_response = client.put(upload_url)
                            .body(body)
                            .send()
                            .await
                            .unwrap();

// Do something with the response
println!("{:#?}", upload_response);

// Request to finish a staging object only needed in case of no upload or multipart upload

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
# Create tonic/ArunaAPI request to re-upload the modified data
update_request = UpdateObjectRequest(
    object_id="<object-id>",
    collection_id="<collection-id>",
    object=StageObject(
        filename="aruna.png",
        content_len=1234567,
        source=None,  # Parameter can also be omitted if None
        dataclass=DataClass.Value("DATACLASS_PRIVATE"),
        labels=[KeyValue(
            key="LabelKey",
            value="LabelValue"
        )],
        hooks=[KeyValue(
            key="HookKey",
            value="HookValue"
        )],
        subPath="",  # Parameter can also be omitted if empty
    ),
    reupload=True,
    preferred_endpoint_id="",  # Parameter can also be omitted if empty
    multi_part=False,  # Parameter can also be omitted if `reupload=False`
    is_specification=False,
    force=False,
    hash=None  # Will be provided at object finish in this example
)

# Send the request to the AOS instance gRPC gateway
update_response = client.object_client.UpdateObject(request=update_request)

# Do something with the response
print(f'{update_response}')

# Create tonic/ArunaAPI request to request an upload url for single part upload
get_request = GetUploadURLRequest(
    object_id=update_response.object_id,
    upload_id=update_response.upload_id,
    collection_id=update_response.collection_id,
    multipart=False,
    part_number=1
)

# Send the request to the AOS instance gRPC gateway
get_response = client.object_client.GetUploadURL(request=get_request)

# Do something with the response
print(f'{get_response}')
upload_url = get_response.url.url

# Upload updated local file to the generated upload URL
file_path = "/path/to/updated/local/file"
headers = {'Content-type': 'application/octet-stream'}
upload_response = requests.put(upload_url, data=open(file_path, 'rb'), headers=headers)

# Do something with the response (e.g. check status if was successful)
print(f'{upload_response}')

# Request to finish a staging object only needed in case of no upload or multipart upload

Create Object reference

References of an Object can be created in other Collections, which points to the same object in the database. A reference can be either "read only", which means that the Object can not be modified from the specific Collection, or writeable, in which case the object in the target collection will be no different from the one in the source collection.

Warning

Updates on writeable references also update the Object in all other Collections the Object is referenced in.

Info

This request needs permission in the source and target Collection. The required permissions on the source collection depend on whether the reference should be writeable or not:

  • true: At least MODIFY on the source Collection or the Project under which the Collection is registered
  • false: At least READ on the source Collection or the Project under which the Collection is registered

Additionally, the request needs MODIFY permissions on the target Collection or the Project under which the Collection is registered.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
# Native JSON request to create an auto-updated read-only reference to keep track of an object
curl -d '
  {
    "writeable": false,
    "autoUpdate": true,
    "subPath": ""
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X POST https://<URL-to-AOS-instance-API-gateway>/v1/collection/<source-collection-id>/object/<object-id>/reference/<destination-collection-id>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
# Native JSON request to create a writeable reference in another collection for collaborative work
curl -d '
  {
    "writeable": true,
    "autoUpdate": true
    "subPath": ""
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X POST https://<URL-to-AOS-instance-API-gateway>/v1/collection/<source-collection-id>/object/<object-id>/reference/<destination-collection-id>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
// Create tonic/ArunaAPI request to create an auto-updated read-only reference to keep track of an object
let create_request = CreateObjectReferenceRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<source-collection-id>".to_string(),
    target_collection_id: "<target-collection-id>".to_string(),
    writeable: false,
    auto_update: true,
    sub_path: "".to_string(),
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.create_object_reference(create_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
// Create tonic/ArunaAPI request to create a writeable reference in another collection for collaborative work
let create_request = CreateObjectReferenceRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<source-collection-id>".to_string(),
    target_collection_id: "<target-collection-id>".to_string(),
    writeable: true,
    auto_update: true,
    sub_path: "".to_string(),
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.create_object_reference(create_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
# Create tonic/ArunaAPI request to create an auto-updated read-only reference to keep track of an object
request = CreateObjectReferenceRequest(
    object_id="<object-id>",
    collection_id="<source-collection-id>",
    target_collection_id="<target-collection-id>",
    writeable=False,
    auto_update=True,
    subPath="",  # Parameter can also be omitted if empty
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.CreateObjectReference(request=request)

# Do something with the response
print(f'{response}')

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
# Create tonic/ArunaAPI request to create a writeable reference in another collection for collaborative work
request = CreateObjectReferenceRequest(
    object_id="<object-id>",
    collection_id="<source-collection-id>",
    target_collection_id="<target-collection-id>",
    writeable=True,
    auto_update=True,
    subPath="",  # Parameter can also be omitted if empty
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.CreateObjectReference(request=request)

# Do something with the response
print(f'{response}')

Move Object to other Collection

Objects can be moved to another Collection without cloning. E.g. this can be used to transfer Collection ownership of an Object.

This process consists of two steps:

  1. Create writeable reference of the Object in another Collection
  2. Delete reference of the Object in the source Collection
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
# Native JSON request to create a writeable reference in another collection
curl -d '
  {
    "writeable": true,
    "autoUpdate": true
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X POST https://<URL-to-AOS-instance-API-gateway>/v1/collection/<source-collection-id>/object/<object-id>/reference/<target-collection-id>

# Native JSON request to delete writeable reference in source collection
curl -d '
  {
    "withRevisions": true,
    "force": false
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X DELETE https://<URL-to-AOS-instance-API-gateway>/v1/collection/<source-collection-id>/object/<source-object-id>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
// Create tonic/ArunaAPI request to create a writeable reference in another collection
let create_request = CreateObjectReferenceRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<source-collection-id>".to_string(),
    target_collection_id: "<target-collection-id>".to_string(),
    writeable: true,
    auto_update: true,
};

// Send the request to the AOS instance gRPC gateway
let create_response = object_client.create_object_reference(create_request)
                                   .await
                                   .unwrap()
                                   .into_inner();

// Do something with the response
println!("{:#?}", create_response);

// Create tonic/ArunaAPI request to delete the object in the source collection
let delete_request = DeleteObjectRequest {
    object_id: "<source-object-id>".to_string(),
    collection_id: "<source-collection-id>".to_string(),
    with_revisions: true,
    force: false,
};

// Send the request to the AOS instance gRPC gateway
let delete_response = object_client.delete_object(delete_request)
                                   .await
                                   .unwrap()
                                   .into_inner();

// Do something with the response
println!("{:#?}", delete_response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
# Create tonic/ArunaAPI request to create a writeable reference in another collection
create_request = CreateObjectReferenceRequest(
    object_id="<object-id>",
    collection_id="<source-collection-id>",
    target_collection_id="<target-collection-id>",
    writeable=True,
    auto_update=True
)

# Send the request to the AOS instance gRPC gateway
create_response = client.object_client.CreateObjectReference(request=create_request)

# Do something with the response
print(f'{create_response}')

# Create tonic/ArunaAPI request to delete the object in the source collection
delete_request = DeleteObjectRequest(
    object_id="<source-object-id>",
    collection_id="<source-collection-id>",
    with_revisions=True,
    force=False
)

# Send the request to the AOS instance gRPC gateway
delete_response = client.object_client.DeleteObject(request=delete_request)

# Do something with the response
print(f'Deleted: {delete_response}')

Get all Object references

You can fetch information of all references an Object has in different Collections.

Info

This request needs at least READ permissions on the Object's Collection or the Project under which the Collection is registered.

1
2
3
4
# Native JSON request to fetch all references of an object
curl -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X GET https://<URL-to-AOS-instance-API-gateway>/v1/collection/<collection-id>/object/<object-id>/references

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
// Create tonic/ArunaAPI request to fetch all references of an object
let get_request = GetReferencesRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    with_revisions: false
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.get_references(get_request)
                            .await
                            .unwrap()
                            .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# Create tonic/ArunaAPI request to
request = GetReferencesRequest(
    object_id="<object-id>",
    collection_id="<collection-id>",
    with_revisions=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.GetReferences(request=request)

# Do something with the response
print(f'Deleted: {response}')

Delete Object

Objects can also be deleted again according to the FAIR guidelines.

This means that deleted objects or individually deleted revisions of objects do not simply disappear, but a reference to the deleted resource remains.

Object deletion rulebook:

Deletion of the last reference of an Object deletes the complete Object.

Visualization what happens if the last reference of an object gets deleted.

Deleting a reference of an object while other references still exist only removes the specific reference.

Visualization what happens if some reference of an object gets deleted.

If the last existing reference of an Object is writeable == false (i.e. read-only) the Object exists without possibility of further modification.

Visualization what happens if the last writeable reference of an object gets deleted.

With force == true an Objects revision can be deleted without regards to other references.

Visualization what happens if an object revision gets forcefully deleted.

With force == true and with_revisions == true an Object can be deleted completely without regards to other references.

Visualization what happens if all object revisions get forcefully deleted.

Deletion of Objects from versioned Collections is prohibited without exceptions.

Info

The required permissions of this request depend on the value of the force parameter:

  • true: At least ADMIN on the source Collection or the Project under which the Collection is registered
  • false: At least APPEND on the source Collection or the Project under which the Collection is registered

All conditions can be overwritten with the use of force = true in the request but this should be avoided at all costs. Therefore, only users with ADMIN permissions on the Project can use force = true in the request.

1
2
3
4
5
6
7
8
9
# Native JSON request to force delete an object with all its revisions
curl -d \
  '{
    "withRevisions": "false",
    "force": "false"
  }' \
     -H 'Authorization: Bearer <API_TOKEN>' \
     -H 'Content-Type: application/json' \
     -X DELETE https://<URL-to-AOS-instance-API-gateway>/v1/collection/<collection-id>/object/<object-id>

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
// Create tonic/ArunaAPI request to delete an object with all its revisions
let delete_request = DeleteObjectRequest {
    object_id: "<object-id>".to_string(),
    collection_id: "<collection-id>".to_string(),
    with_revisions: false,
    force: false,
};

// Send the request to the AOS instance gRPC gateway
let response = object_client.delete_object(delete_request)
                                   .await
                                   .unwrap()
                                   .into_inner();

// Do something with the response
println!("{:#?}", response);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
# Create tonic/ArunaAPI request to delete an object with all its revisions
request = DeleteObjectRequest(
    object_id="<source-object-id>",
    collection_id="<source-collection-id>",
    with_revisions=False,
    force=False
)

# Send the request to the AOS instance gRPC gateway
response = client.object_client.DeleteObject(request=request)

# Do something with the response
print(f'{response}')
